ZLTECH 42mm 24V 1.5A 0.5Nm CANopen yakabatanidzwa nhanho mota uye mutyairi we 3D printer

Tsanangudzo Pfupi

Iyo 42 yakavhurika-loop stepper CANOPEN yakakamurwa kuita mhando mbiri, ZLIM42C-05, ZLIM42C-07.

ZLTECH Nema17 0.5-0.7NM 18V-28VDC CANopen Yakabatanidzwa Nhanho-Servo Motor

Kuita kweiyo 42 yakavhurika-loop CANIPEN stepper inoteedzera seinotevera:

Shaft: Shaft imwe chete

Size: Nema 17

nhanho kona: 1.8°

Ebcoder: 2500-waya Magnetic

Input voltage (VDC): 20-48

Kubuda parizvino peak(A):1.5

shaft dhayamita(mm): 5/8

kureba kweshaft(mm): 24

Kubata Torque(Nm): 0.5/0.7

Kumhanya (RPM): 2000

Kurema (g): 430g

Motokari Kureba(mm);70/82

Motokari inokwana Kureba(mm): 94/106

Tumira email kwatiri

Product Detail

Product Tags

Outline

Iyo ZLIM42C ndeye 2 chikamu dhijitari nhanho-servo mota ine yakakwirira-inoshanda dhijitari yakabatanidzwa mutyairi.Iyo sisitimu ine chimiro chakareruka uye yakanyanya kubatanidzwa, uye inowedzera kutaurirana kwebhazi uye single-axis controller mabasa.Kutaurirana kwebhazi kunotora CAN bhazi interface, uye inotsigira CiA301 uye CiA402 sub-protocols yeCANopen protocol.

Profile yekambani

Zhongling Technology yanga yakatarisana nezvigadzirwa zvemaindasitiri otomatiki, izvo zvinogona kugadzirwa zvinoenderana nezvinodiwa nevatengi.Nehunhu hwekutarisisa, hutsva, hutsika uye pragmatism, isu tinopa vatengi zvigadzirwa zvekutanga-kirasi uye mhinduro, kuitira kuti wese mudiwa anogona kushandisa zvigadzirwa zvedu nechivimbo.Batira pamwe nemazana emabhizinesi, zvikoro, nezvimwewo, tevedzera kuenderera mberi hunyanzvi kuunza vatengi zvigadzirwa zvakanakisa, tsvagiridzo yekutengesa yakazara uye hurongwa hwekusimudzira, kupa vatengi ruzivo rwekutenga rwakanyanya.Uye ine yakapfuma chigadzirwa mutsara 4-15 inch hub mota, 100-3000W servo mota, yakasanganiswa stepper mota, nezvimwewo kuti indasitiri yemarobhoti ipe zvigadzirwa zvakanakisa uye zvakakodzera, ruzivo runogona kuwanikwa pawebhusaiti yepamutemo (http:/ /www.zlingkj.com/).

Parameters

CANOPEN	ZLIM42C-05	ZLIM42C-07
Shaft	Single shaft	Single shaft
Size	Nema17	Nema17
step angle	1.8°	1.8°
Input voltage (VDC)	20-48	20-48
Kubuda parizvino peak(A)	1.5	1.5
Nhanho yechiratidzo frequency (Hz)	200k	200k
Dzora chiratidzo chekuisa ikozvino (mA)	10	10
Over-voltage protection (VDC)	29	29
Input signal voltage (VDC)	5	5
shaft dhayamita (mm)	5/8	5/8
kureba kweshaft (mm)	24	24
Kubata Torque(Nm)	0.5	0.7
Kumhanya (RPM)	2000	2000
Encoder	/	/
Insulation kuramba (MΩ)	100	100
Sevhisi tembiricha(℃)	0~50	0~50
Max.ambient humidity	90% RH	90% RH
Kuchengetedza tembiricha (℃)	-10~70	-10~70
Vibration	10 ~ 55Hz/0.15mm	10 ~ 55Hz/0.15mm
Huremu(g)	430	430
Kureba kweMota(mm)	70	82
Motokari Yese kureba(mm)	94	106
Encoder	/	/
